AFFF Foam Safety Fire Extinguisher 5kg ISO 9001 BS EN3
  • AFFF Foam Safety Fire Extinguisher 5kg ISO 9001 BS EN3
  • AFFF Foam Safety Fire Extinguisher 5kg ISO 9001 BS EN3
  • AFFF Foam Safety Fire Extinguisher 5kg ISO 9001 BS EN3
  • AFFF Foam Safety Fire Extinguisher 5kg ISO 9001 BS EN3
  • AFFF Foam Safety Fire Extinguisher 5kg ISO 9001 BS EN3
  • AFFF Foam Safety Fire Extinguisher 5kg ISO 9001 BS EN3

AFFF Foam Safety Fire Extinguisher 5kg ISO 9001 BS EN3

Place of Origin China
Brand Name Safeway Fire
Certification Normal
Model Number SWDF-05
Product Details
Product Name:
5kg Wholesale Portable Dry Powder Fire Extinguisher With High Quality
Out-Dia:
140mm
Cylinder Height:
420mm
Powder Weight:
5kg
Thickness:
1.2mm
Carton Size:
52*29*15cm/2pcs
Gross Weight:
16kg
High Light:

AFFF foam safety fire extinguisher

,

BS EN3 safety fire extinguisher

,

ISO 9001 5kg fire extinguisher

Product Description

5kg Wholesale Portable Dry Powder Fire Extinguisher For Wide Use

1. 5kg Wholesale Portable Dry Powder Fire Extinguisher
The SAFEFIRE range of portable cartridge operated type fire extinguishers is certified to BS EN3 and is manufactured under an ISO 9001 approved Quality System. Extinguishers are available in a wide range of sizes with ABC dry powder, Monnex powder, AFFF foam and water models.



2. The extinguisher bodies are fully deep drawn from cold rolled steel, and pressure tested to twice the extinguisher’s working pressure. Cylinders are externally coated with polyester (with phosphate under treatment) for maximum corrosion resistance and have passed the 480-hour salt spray test. The water and foam extinguishers are internally coated with “performance polymer alloy” to prevent corrosion. Its chrome plated operating brass headcap is fitted with a safety relief valve.



3. Dry Powder (ABC): ABC dry powder extinguisher is effective on Class A (carbonaceous) fire, Class B (flammable liquid) fire and Class C (flammable gas) fire. It is also suitable for use on live electrical fires.
Monnex Powder: Monnex powder extinguisher is recommended for high risk areas where rapid knockdown is required on Class B and C fires. Monnex is particularly suitable for use in refineries, petrochemical complexes and other high hazard areas.


PRODUCT DESCRIPTIONS

1.The standard dry powder extinguishers are also known as ABC extinguishers as these can be used for

class A, class B and class C fires.



2.Dry powder extinguishers smother fires by forming a barrier between the fuel and source of oxygen.

The label colour for this type of extinguisher is blue.



3.This type of fire extinguisher may be used for fires caused by various organic materials including

wood, coal, textiles, fabrics, cardboard and paper among others.



4.It may also be used for fires caused by flammable liquids including petrol and paint as well as

flammable gases including acetylene and liquid petroleum gas.

Any fires that involve electrical equipment up to 1000 V may also be dealt with the help of this fire extinguisher.




PRODUCT SPECIFICATIONS



Item No. SWDF-0.5 SWDF-01 SWDF-02 SWDF-03 SWDF-04 SWDF-4.5 SWDF-05 SWDF-06 SWFP-08 SWFP-09 SWFP-10 SWFP-12
Capacity 0.5KG 1KG 2KG 3KG 4KG 4.5KG 5KG 6KG 8KG 9KG 10KG 12KG
Out-Dia 67mm 90mm 110mm 130mm 130mm 130mm 140mm 160mm 160mm 182mm 182mm 182mm
Cylinder Height 230mm 250mm 305mm 350mm 410mm 410mm 420mm 420mm 500mm 500mm 550mm 600mm
Powder Weight 0.5KG 1KG 2KG 3KG 4KG 4.5KG 5KG 6KG 8KG 9KG 10KG 12KG

Thick

-ness

0.9mm 0.9mm 1mm 1.2mm 1.2mm 1.2mm 1.2mm 1.2mm 1.2mm 1.5mm 1.5mm 1.5mm

Temp

Range

-30℃~

+60℃

-30℃~

+60℃

-30℃~

+60℃

-30℃~

+60℃

-30℃~

+60℃

-30℃~

+60℃

-30℃~

+60℃

-30℃~

+60℃

-30℃~

+60℃

-30℃~

+60℃

-30℃~

+60℃

-30℃~

+60℃

MAX W.P.

14Bar 14Bar 14Bar 14Bar 14Bar 14Bar 14Bar 14Bar 14Bar 14Bar 14Bar 14Bar
Test Pressure 25Bar 25Bar 25Bar 25Bar 25Bar 25Bar 25Bar 25Bar 25Bar 25Bar 25Bar 25Bar
Material St12 St12 St12 St12 St12 St12 St12 St12 St12 St12 St12 St12

Carton Size

37.5*15*

30cm/10

pcs

49*20*33

cm/10pcs

36*24*40

cm/6pcs

45*27*14

cm/2pcs

50*27*14

cm/2pcs

52*29*15

cm/2pcs

52*29*15

cm/2pcs

52*33*17

cm/2pcs

17*17*60

cm/pc

19*19*60

cm/pc

19*19*65

cm/pc

19*19*70

cm/pc

Gross Weight 13KG 16.5KG 21KG 10KG 12.8KG 14.4KG 16KG 17.6KG 11.5KG 13KG 14.5KG 17KG





PRODUCT ADVANTAGES



1.European standard extinguisher manufactured with ISO, CE and EN3 certificate.



2.Each fire extinguisher pass water leakage test before leaves factory.

3.Label, screen printing, carton, logo, marking could be design per your standard.

4.Easy to use.
